Compass HD
Rental inquiry
Ask about rental options
Call our team to discuss rental options for this product.
Measurements and options
Specifications
Specs
- Drive Range
- 12.00 miles
- Top Speed
- 4.00 mph
- Disassembles/Folds
- No
- Overall Width
- 25.00″
- Overall Length
- 40.00″
- Heaviest Piece
- 101 lbs.
- Turning Radius
- 20.00″
- Ground Clearance
- 3.50″
- Tire Type
- Foam Filled
- Maximum Incline Rating
- 6 º
- Drive Type
- Mid Wheel Drive
- Foldable
- Yes
- Armrest Options
- Height Adjustable Flip-Back
- Legrest Options
- Footplate Elevating Legrests Swing-Away Legrests
- Seat Options
- Reclining Back Captain’s Seat
- Power Chair Seat Width
- 20″ 22″ 24″
- Seat Width Ranges
- 20″ – 21″ 22″ – 23″ 24″ – 25″
- Seat Depths
- 20″
- Maximum Seat to Floor Height
- 23.00″
- Back Height
- 21″ 23″
- Joystick Options
- Right Swing-Away
- Adjustable Angle Footplates
- Yes
- Dampening Adjustment
- No
- Battery Type
- 2-NF22
- Batteries Included
- Yes
- Battery Charger Type
- Off Board
- Drive Wheel Size
- 10″
- Caster Size
- 6″
- Rear Caster Size
- 6″
- Base Weight
- 101.00 lbs.
- Battery Pack Weight
- 74.00 lbs.
- Weight Without Batteries
- 155.00 lbs.
- Standard Seat Weight
- 51.00 lbs.
- Controller Type
- Dynamic 75 Amp Remote
- Suspension
- No
Approximate Shipping Dimensions and Weights
- Product Weight
- 209 lbs.
- Box
- 1
- Shipping Weight
- 210.00 lbs.
- Length
- 34.00″
- Width
- 26.00″
- Height
- 18.00″
